Bomag BW 24 RH, BW 27 RH Rubber Tire Roller Operating and Maintenance Instructions 00812631

$20.00

Type Of Manual: Operating and Maintenance Instructions
Manual ID: 00812631
Format: PDF
Size: 3.2MB
Number of Pages: 110
Serial Number:
10153800, 10153810

Category: Bomag Operator Manual PDF

Model List:
- BW 24 RH Rubber Tire Roller
- BW 27 RH Rubber Tire Roller

1. BW 24/27 RH
2. Rubber tire roller
3. General notes
4. Description of indicators and control elements
5. General notes
6. Tests before taking into operation
7. Disarming the antitheft protection
8. Starting the engine
9. Starting with jump wires
10. Driving the machine / braking
11. Operating the parking brake
12. Shutting the engine down, parking the machine
13. In events of emergency
14. Operating the pressure sprinkler system
15. Operating the tire inflation system
16. Adjusting the drivers seat
17. Operating the hood
18. Ballasting of machine
19. Towing in case of an engine failure
20. Transport
21. General notes on maintenance
22. Fuels and lubricants
23. Table of fuels and lubricants
24. Runningin instructions
25. Maintenance chart
26. Check the engine oil level
27. Check, clean the water separator
28. Check the coolant level
29. Check the hydraulic oil level
30. Draining the air pressure vessel
31. Checking/filling up the water provision in the sprinkler system
32. Checking/adjusting the scrapers
33. Check the fuel level
34. Multidisc brake, function test
35. Clean the cooling fins on engine and hydraulic oil cooler
36. Check the oil level in the drive gear/wheel hub
37. Changing engine oil and oil filter cartridges
38. Change the fuel filter cartridge
39. Drain the sludge from the fuel tank
40. Battery maintenance
41. Change the fuel prefilter cartridge
42. Checking, replacing the refrigerant compressor V belt
43. Service the air conditioning
44. Checking hydraulic, pneumatic hoses and electric cables
45. Check, adjust the valve clearance
46. Checking / replacing the ribbed Vbelt
47. Check the engine mounts
48. Tighten the wheel nuts
49. Checking the Roll Over Protective Structure (ROPS/ FOPS)
50. Changing the air drier for the brake system
51. Changing the oil in travel gears/wheel hubs
52. Changing hydraulic oil and breather filter
53. Changing the hydraulic oil filter
54. Change the coolant
55. Checking the supply lines for the compressor
56. Checking the injection valves
57. Service the combustion air filter
58. Servicing the water sprinkling system
59. Maintenance in case of frost
60. Filling the windscreen washer system
61. Changing the fresh air filter in the cabin
62. Change the tires
63. Check bolted connections for tight fit
64. Temporary taking out of service
65. General notes
66. Engine
