Komatsu FG35Z-7, FG40Z-7, FG35-7, FG40-7, FG45-7, FD35Z-7, FD40Z-7, FD35-7, FD40-7, FD45-7, FD50A-7 Forklift Truck Shop Manual BEC07E1-01

$50.00

  • Type Of Manual: Shop Manual
  • Manual ID: BEC07E1-01
  • Format: PDF
  • Size: 21.8MB
  • Number of Pages: 343

Description

  • Model List:

    • FG35Z-7 Forklift Truck
    • FG40Z-7 Forklift Truck
    • FG35-7 Forklift Truck
    • FG40-7 Forklift Truck
    • FG45-7 Forklift Truck
    • FD35Z-7 Forklift Truck
    • FD40Z-7 Forklift Truck
    • FD35-7 Forklift Truck
    • FD40-7 Forklift Truck
    • FD45-7 Forklift Truck
    • FD50A-7 Forklift Truck
  • 1. Title Page BEC07E101
  • 2. Section Index
  • 3. General and Specifications
  • 3.1. Specifications
  • 3.2. Periodic Replacement of Consumable Parts
  • 3.3. Safety Items for Maintenance
  • 3.4. Standard Tightening Torque for Bolts
  • 3.5. Standard Tightening Torque for Pipe Joints
  • 4. Testing and Adjusting
  • 4.1. Service Data
  • 4.2. Diesel Engine
  • 4.3. Gasoline Engine
  • 4.4. Air Cleaner
  • 4.5. Method of Adjusting Ignition Timing
  • 4.6. Method of Adjusting Injection Timing
  • 4.7. Measuring Method for Compression
  • 4.8. Adjustment Method of Valve Clearance
  • 4.9. Tightening Torque for Cylinder Head Mounting Bolts
  • 4.10. Adjusting Accelerator Pedal (TB42 Engine Truck)
  • 4.11. Adjusting Accelerator Pedal (6D102E Engine Truck)
  • 4.12. Adjusting Accelerator PowerAssistType Clutch/Brake Pedal (Oil Clutch Truck)
  • 4.13. Adjusting Inching/Brake Pedal (TORQFLOW Truck)
  • 4.14. Wheel Brake
  • 4.15. Adjusting Parking Brake Lever
  • 4.16. TORQFLOW Transmission Case (TORQFLOW Type Only)
  • 4.17. Differential Case
  • 4.18. Hydraulic Tank
  • 4.19. Measuring Hydraulic Drift of Lift Cylinder, Tilt Cylinder
  • 4.20. Adjusting the Mast
  • 4.21. Adjusting the Finger Bar
  • 4.22. Cooling System
  • 4.23. Bleeding Air
  • 4.24. Positions to Grease
  • 5. Removal and Installation
  • 5.1. Unit Installation Positions
  • 5.2. Overall Disassembly and Assembly Flowchart
  • 5.3. Weight Table
  • 5.4. Overall Disassembly and Assembly Drawing
  • 5.5. Mast
  • 5.6. Lift Cylinder
  • 5.7. Engine
  • 5.8. Clutch (Clutch truck)/Torque Converter (TOQFLOW truck) Transmission Drive Axle
  • 5.9. Steering Axle and Power Steering Cylinder
  • 5.10. Wheel Brake
  • 6. Disassembly and Assembly
  • 6.1. Oil Clutch
  • 6.2. Clutch Booster and Master Cylinder
  • 6.3. Clutch Release Cylinder
  • 6.4. Transmission
  • 6.5. Torque Converter
  • 6.6. TORQFLOW Transmission
  • 6.7. Transmission Control Valve
  • 6.8. Differential
  • 6.9. Drive Axle
  • 6.10. Wheel Brake
  • 6.11. Brake and Clutch Boosters
  • 6.12. Rear Axle
  • 6.13. Steering Gear Box
  • 6.14. Combination Switch
  • 6.15. Hydraulic Pump
  • 6.16. Flow Divider
  • 6.17. Control Valve
  • 6.18. Lift Cylinder
  • 6.19. Tilt Cylinder (6 and 12 degree type)
  • 6.20. Power Steering Cylinder
  • 6.21. Mast
  • 6.22. Finger Board
  • 6.23. Special Tool List
  • 7. Maintenance Standard
  • 7.1. Oil Clutch
  • 7.2. Transmission
  • 7.3. Torque Converter
  • 7.4. TORQFLOW Transmission (F1/R1)
  • 7.5. TORQFLOW Transmission (F2/R1)
  • 7.6. Transmission Control Valve
  • 7.7. Differential
  • 7.8. Wheel Brake
  • 7.9. Brake Master Cylinder
  • 7.10. Clutch Booster and Master Cylinder
  • 7.11. Clutch Release Cylinder
  • 7.12. Steering Gear Box
  • 7.13. Flow Divider
  • 7.14. Lift Cylinder
  • 7.15. Tilt Cylinder
  • 7.16. Power Steering Cylinder
  • 7.17. Mast, Fork Carriage
  • 7.18. Finger Board
  • 7.19. Steering (Rear) Axle
  • 8. Structure and Function
  • 8.1. Torque Converter/Transmission Control Valve
  • 8.2. Hydraulic Pump (Work Equipment and Clutch/Brake Boosters)
  • 8.3. Hydraulic Circuit Diagram
  • 8.4. Flow Divider
  • 8.5. Work Equipment Control Valve
  • 8.6. Brake and Clutch Booster
  • 8.7. Power Steering
  • 9. Assembly Drawings
  • 9.1. Electrical Circuit Diagram (Gasoline Engine)
  • 9.2. Electrical Circuit Diagram (Diesel Engine)
  • 9.3. Electrical Wiring Diagram (6D102E)
  • 9.4. TORQFLOW Transmission (for F1/R1)
  • 9.5. TORQFLOW Transmission (for F2/R1)
  • 9.6. General View of TORQFLOW Transmission (F2/R1)
  • 9.7. Clutch Transmission
  • 9.8. Transmission (ClutchType), Shifter, Yoke, and Outer Appearance)
  • 9.9. Pinion Shaft (TORQFLOW Type)
  • 9.10. Drive Axle (Standard)
  • 9.11. Wheel Brake (FGD3545, 50A)
  • 9.12. Wheel Brake (FGD33N/35N)
  • 9.13. Mast (FGD35/40)
  • 9.14. Finger Board (3.3N 4.0 ton, w/Mast STD Dimensions)
  • 10. Troubleshooting
  • 10.1. Engine
  • 10.2. Electrical System
  • 10.3. Clutch and Clutch Transmission
  • 10.4. TORQFLOW System
  • 10.5. Steering System
  • 10.6. Brake System
  • 10.7. Hydraulic System
  • 11. Conversion Tables
  • 11.1. Millimeters to Inches
  • 11.2. Inches to Millimeters
  • 11.3. Cubic Meters to Cubic Yards
  • 11.4. Cubic Yards to Cubic Meters
  • 11.5. Liter to U.S. Gallon
  • 11.6. Gallon to Liter
  • 11.7. Liter to U.K. Gallon
  • 11.8. Gallon to Liter
  • 11.9. Kilogram to Pound
  • 11.10. Pound to Kilogram
  • 11.11. Kg/cm (squared) to lb/in.(squared)
  • 11.12. kgm to ft.lb
  • 11.13. Temperature
