New Holland 9090X Dual, 9090X Olive, 9090X Olive Side Conveyor, 9090X Side Conveyor Grape Harvester Service Manual 51697893

Description

• Model List:
  • 9090X Dual Grape Harvester
  • 9090X Olive Grape Harvester
  • 9090X Olive Side Conveyor Grape Harvester
  • 9090X Side Conveyor Grape Harvester

• 1. Contents
• 2. INTRODUCTION
• 3. Engine 10
• 4. Hydrostatic drive 29
• 5. Brakes and controls 33
• 6. Hydraulic systems 35
• 7. Frames and ballasting 39
• 8. Steering 41
• 9. Wheels 44
• 10. Cab climate control 50
• 11. Electrical systems 55
• 12. Fruit harvester shaking 56
• 13. Product feeding 60
• 14. Cleaning 74
• 15. Secondary cleaning/Destemmer 76
• 16. Crop storage / Unloading 80
• 17. Accessories 88
• 18. Tools 89
• 19. Platform, cab, bodywork, and decals 90
• 20. Residue handling 73
• 21. SPECIAL TOOL INDEX
