New Holland BC5050, BC5060, BC5070, BC5070 Hayliner, BC5080 Square Baler Service Manual 47936444

Description

• Model List:
  • BC5050 Square Baler
  • BC5060 Square Baler
  • BC5070 Square Baler
  • BC5070 Hayliner Square Baler
  • BC5080 Square Baler

• 1. Tying/Wrapping/Twisting 68
• 1.1. Knotter drive system 100
• 1.2. Knotter clutch and brake 110
• 1.3. Knotter trip mechanism 120
• 1.4. Needles 130
• 1.5. Knotter stack 140
• 1.6. Twine guide system 150
• 1.7. Knotter frame 160
• 1.8. Twister frame 900
• 1.9. Twister stack 901
• 1.10. Twister drive system 902
• 1.11. Twister clutch and brake 903
