Komatsu D275A-5R Bull Dozer Field Assembly Instruction GEN00067-02

Description

• Model List:
  • D275A-5R Bull Dozer

• 1. Cover
• 2. Preface
• 3. Specifications
• 4. Assembly procedure, necessary equipment, and schedule
• 5. Layout of kit
• 6. Style for transportation
• 7. Tools list for field assembly
• 8. Sketch of tools
• 9. Tightening torque
• 10. Coating materials
• 11. Assembly
• 11.1. A1 Installation of chassis
• 11.2. A2 Installation of track frame
• 11.3. A3 Installation of ripper
• 11.4. A4 Adding oil to pivot chamber
• 11.5. A5 Installing track shoes
• 11.6. A6 Assembly of blade (For SemiUdozer Udozer)
• 11.7. A7 Assembly of blade (For Sigmadozer)
• 11.8. A8 Installation of blade
• 11.9. A9 Installation of operators cab
• 11.10. A10 Installation of ROPS
• 11.11. A11 Check track tension
• 11.12. A12 Check of oil and coolant levels
• 11.13. A13 Lubricating
• 11.14. A14 Bleeding air from hydraulic cylinders
• 11.15. A15 Installation of KOMTRAX antenna
• 11.16. A16 Installing lunchbox band (if equipped)
• 11.17. A16 Installing lunchbox band (if equipped)
• 12. Check and maintenance procedures after completion of assembly
• 12.1. M1 Check and adjustment of operators cab
• 12.2. M2 Inspection of machine monitor
• 13. Field assembly inspection report
