Description
-
Model List:
- D375A-8E0 Bull Dozer
- 1. Cover
- 2. Preface
- 3. CONTENTS
- 4. Specifications
- 5. Precautions for field assembly
- 6. Disposal of removed parts
- 7. Assembly procedure, necessary equipment, and schedule
- 8. Layout of kit
- 9. Style for transportation
- 10. Table of tools for field assembly
- 11. Sketch of jigs
- 12. Tightening torque
- 13. Coating materials list
- 14. Selection of wire ropes used for assembly
- 15. Assembly
- 15.1. A1 Installation of chassis
- 15.2. A2 Installation of final drive assy
- 15.3. A3 Installation of undercarriage
- 15.4. A4 Adding oil to recoil chamber and pivot chamber
- 15.5. A5 Installing direction of exhaust pipe
- 15.6. A6 Installation of blade lift cylinder
- 15.7. A7 Installation of cylinder yoke grease hose
- 15.8. A8 Installation of ripper
- 15.9. A9 Installation of grease hose of ripper pin (if equipped)
- 15.10. A10 Installation of track
- 15.11. A11 Assembly of blade
- 15.12. A12 Installation of blade
- 15.13. A13 Installation of Komtrax antenna
- 15.14. A14 Installation of ROPS guard
- 15.15. A15 Installation of platform (if equipped)
- 15.16. A16 Check track tension
- 15.17. A17 Check fuel, coolant and lubricants
- 15.18. A18 Bleeding air from hydraulic cylinders
- 15.19. A19 Lubricating
- 15.20. A20 Installation of fuel quick charge piping(if equipped)
- 15.21. A21 Installation of ladder pump and switches(if equipped)
- 15.22. A22 Installation of ladder (if equipped)
- 16. Check and maintenance procedures after completion of assembly
- 16.1. M1 Inspection of machine monitor
- 16.2. M2 Setting procedure for USER ADJUST MODE
- 16.3. M3 Replacement of return filter (Replacement of standard filter special flushing parts)
- 16.4. M4 Flushing of hydraulic circuit, and bleeding air from hydraulic cylinders (Part 1)
- 16.5. M5 Replacement of return filter (Replacement of special flushing parts standard filter)
- 16.6. M6 Bleeding air from hydraulic cylinders (Part 2)
- 16.7. M7 Method for starting up KOMTRAX terminal and default setting of KOMTRAX Plus controller
- 17. Field assembly inspection report
