Komatsu D275A-6 Bull Dozer Field Assembly Instruction GEN00254-01

Description

• Model List:
  • D275A-6 Bull Dozer

• 1. Cover
• 2. Preface
• 3. Specifications
• 4. Precautions for field assembly
• 5. Assembly procedure, necessary equipment, and schedule
• 6. Layout of kit
• 7. Style for transportation
• 8. Tools list for field assembly
• 9. Sketch of tools
• 10. Tightening torque
• 11. Coating materials
• 12. Assembly
• 12.1. A1 Installation of chassis
• 12.2. A2 Installation of track frame
• 12.3. A3 Installation of ripper
• 12.4. A4 Adding oil to pivot chamber
• 12.5. A5 Installation of track shoes
• 12.6. A6 Assembly of blade (For SemiUdozer Udozer)
• 12.7. A8 Installation of blade
• 12.8. A10 Installation of ROPS
• 12.9. A11 Check of track tension
• 12.10. A12 Check of oil and coolant levels
• 12.11. A13 Lubricating
• 12.12. A14 Bleeding air from hydraulic cylinders
• 12.13. A15 Installation of KOMTRAX antenna
• 12.14. A16 Installation of lunchbox band (if equipped)
• 13. Check and maintenance procedures after completion of assembly
• 13.1. M3 Replacement of return filter (Standard filter to flushing filter)
• 13.2. M4 Flushing of hydraulic circuit, and bleeding air from hydraulic cylinders
• 13.3. M5 Replacement of return filter (Flushing filter to standard filter)
• 13.4. M6 Bleeding air from hydraulic cylinders
• 14. Field assembly inspection report
