Komatsu PC400LC-6 Off Set Boom Specification Field Assembly Instruction GEN00006-00

Description

• Model List:
  • PC400LC-6 Off Set Boom Specification

• 1. COVER
• 2. FOREWORD
• 3. CONTENTS
• 4. PRECAUTIONS DURING OPERATION
• 5. ASSEMBLING PROCEDURES, APPLICABLE EQUIPMENT AND SCHEDULE
• 6. TRANSPORTATION
• 7. TIGHTENING TORQUE
• 8. ASSEMBLY PROCEDURE
• 8.1. A ASSEMBLY PROCEDURE
• 8.1.1. A1 INSTALL COUNTERWEIGHT TO MACHINE BODY ASSEMBLY
• 8.1.2. A2 INSTALL BOOM CYLINDER BOTTOM TO MACHINE BODY ASSEMBLY
• 8.1.3. A3 INSTALL BOOM ASSEMBLY TO MACHINE BODY ASSEMBLY
• 8.1.4. A4 CONNECT RESPECTIVE HOSES TO BOOM FOOT AND BOOM CYLINDERS
• 8.1.5. A5 INSTALL RELAY FOR ADDITIONAL WARK LAMPS TO WIRING HARNESS INSIDE CAB
• 8.1.6. A6 INSTALL OPERATOR CAB
• 8.1.7. A7 INSTALL ADDITIONAL WARK LAMPS
• 8.1.8. A8 JOINT BOOM CYLINDER RODS TO BOOM
• 8.1.9. A9 INSTALL ARM TO BOOM
• 8.1.10. A10 CONNECT BUCKET CYLINDER HOSES
• 8.1.11. A11 INSTALL STEPS AND HANDRAILS TO MACHINE BODY ASSEMBLE
• 8.1.12. A12 INSTALL BUCKET TO ARM
• 8.1.13. A13 INSTALL REAR VIEW MIRRORS
• 8.1.14. A14 PERFORM GEASINGUP
• 9. INSPECTION CHECK SHEET FOR PC400LC6 OFFSET BOOM SPECIFICATION
